We are a China-based factory-direct manufacturer and exporter of FRP utility poles, serving power distribution, telecommunications, coastal and renewable energy projects worldwide. Our pultruded fiberglass poles are lightweight, corrosion-resistant, non-conductive and engineered to withstand harsh environments where traditional wood, steel or concrete poles fail. As an experienced FRP pole supplier, we offer customizable lengths, diameters, wall thicknesses and colors, with IEC, ASTM and ISO-compliant production. Buyers sourcing utility poles from China choose us for stable quality, competitive factory pricing, flexible MOQs and reliable export logistics. Contact us for samples, specifications or a tailored quotation.Our company specializes in the manufacture and export of FRP utility poles from China, with a focus on factory-direct supply for overseas utilities, EPC contractors and telecom integrators. We produce fiberglass-reinforced polymer poles that resist corrosion, UV degradation and electrical conductivity, making them suitable for power lines, communication networks, coastal installations and solar farm infrastructure. Every pole is pultruded under controlled process parameters, and we support custom tooling, private labeling and mixed-container shipments. If you are looking for a dependable FRP utility pole exporter and long-term supplier, our team is ready to support your project from specification to delivery.
Folleto de productos de Hebei Fortis Technology Co., Ltd
Product Advantages
Resistance to UV and Weathering
High-quality FRP utility poles are formulated with UV stabilizers and protective surface veils that resist sun damage, fading and surface degradation. They perform reliably under extreme temperatures, from intense desert heat to freezing winter conditions, without becoming brittle or losing structural integrity. This weather resistance ensures consistent performance across diverse climates and reduces the need for painting, coating or other cosmetic upkeep.
Low Maintenance and Long Service Life
Once installed, FRP utility poles require minimal maintenance. They do not need chemical treatment against rot or insects, nor do they need repainting or rust protection. Their resistance to pests, moisture and corrosion means utilities and telecom operators can avoid the recurring costs associated with wooden pole replacement or steel pole coating. Over a projected service life that often exceeds 30 to 50 years, the total cost of ownership is substantially lower than that of conventional alternatives.
Design Flexibility and Customization
FRP utility poles can be manufactured in a wide range of lengths, diameters, wall thicknesses and colors to meet specific project requirements. They can be produced with integrated features such as climbing steps, cable holes, crossarm mounts and identification markings. This flexibility allows engineers to specify poles that match exact load ratings, span requirements and installation conditions, rather than adapting designs to limited standard sizes. Custom tooling and private labeling are also available for OEM and distributor needs.
Parameter Specifications
|
Product |
FRP Utility pole / telephone pole |
|||
|
Category |
Item |
Performance Requirements |
||
|
Mechanical Properties |
Tensile Strength |
≥500 MPa |
||
|
Flexural Strength |
≥500 MPa |
|||
|
Compressive Strength |
≥300 MPa |
|||
|
Physical Properties |
Flame Resistance |
V-1/0 Grade |
||
|
Chemical Resistance |
Acid Resistance (80°C, 5wt% HCl solution, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥80% |
||
|
Alkali Resistance (80°C, 10wt% NaOH solution, 7 days) |
No powdering, no cracks, flexural modulus retention rate ≥50% |
|||
|
Salt Resistance (80°C, 3wt% NaCl solution, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
Aging Resistance |
Artificial Climate Aging (Method A-1, irradiance, cycle 1, 300h) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
||
|
Hygrothermal Aging (60°C, 93%RH, 12h~25°C/93%RH, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
Constant Humidity and Heat Aging (60°C/93%RH, 28 days) |
No powdering, no cracks, flexural modulus retention rate ≥85% |
|||
|
High-Temperature Resistance (300°C~400°C) |
No powdering, no cracks, flexural modulus retention rate ≥80% |
|||
|
Electrical Properties |
Surface Resistivity |
≥1.0 × 10^10 Ω |
||
|
Volume Resistivity |
≥1.0 × 10^10 Ω•m |
|||
|
Density |
solid |
≤0.25 g/cm³ |
||
|
hollow |
≤2 g/cm³ |
|||
|
Model |
Length (m) |
Top Diameter (mm) |
Standard load (P) |
Standard bending moment (kN.m) |
|
Z Ø190×8×I×FH |
8 |
190 |
3 |
19.35 |
|
Z Ø190×9×I×FH |
9 |
190 |
3 |
21.75 |
|
Z Ø190×10×I×FH |
10 |
190 |
3 |
24.15 |
|
Z Ø190×12×I×FH |
12 |
190 |
3 |
29.25 |
|
Z Ø190×15×I×FH |
15 |
190 |
3 |
36.75 |
|
Z Ø190×18×I×FH |
18 |
190 |
3 |
/ |
|
Z Ø190×8×K×FH |
8 |
190 |
4 |
25.80 |
|
Z Ø190×9×K×FH |
9 |
190 |
4 |
29.00 |
|
Z Ø190×10×K×FH |
10 |
190 |
4 |
32.20 |
|
Z Ø190×12×K×FH |
12 |
190 |
4 |
39.00 |
|
Z Ø190×15×K×FH |
15 |
190 |
4 |
49.00 |
|
Z Ø190×18×K×FH |
18 |
190 |
4 |
61.00 |
|
Z Ø190×8×M×FH |
8 |
190 |
6 |
38.70 |
|
Z Ø190×9×M×FH |
9 |
190 |
6 |
43.50 |
|
Z Ø190×10×M×FH |
10 |
190 |
6 |
48.30 |
|
Z Ø190×12×M×FH |
12 |
190 |
6 |
58.50 |
|
Z Ø190×15×M×FH |
15 |
190 |
6 |
73.50 |
|
Z Ø190×18×M×FH |
18 |
190 |
6 |
91.50 |
|
Z Ø230×8×M×FH |
8 |
230 |
6 |
38.70 |
|
Z Ø230×9×M×FH |
9 |
230 |
6 |
43.50 |
|
Z Ø230×10×M×FH |
10 |
230 |
6 |
48.30 |
|
Z Ø230×12×M×FH |
12 |
230 |
6 |
58.50 |
|
Z Ø230×15×M×FH |
15 |
230 |
6 |
73.50 |
|
Z Ø230×18×M×FH |
18 |
230 |
6 |
91.50 |
